Control Cable solutions are multi-core cables designed for signal transmission, telemetry, and monitoring links in industrial automation and power distribution systems (under 450/750V and 0.6/1kV). Ideal for automated factory floors, machine tools, and control cabinets.

Key Features & Benefits

♦ EMI Mitigation: High-density shielding creates a robust Faraday cage effect. It isolates cross-talk and electromagnetic interference from variable frequency drives (VFDs) and heavy motors.

♦ Easy Installation: Cores feature color coding or continuous, abrasion-resistant white numbers on black insulation. This layout eliminates wiring errors and speeds up terminal connections.

♦ Industrial Customization:

oDrag Chains & Robotics: Fine stranded copper with a rugged Polyurethane (PUR) jacket. Rated for millions of bending cycles; resists mechanical tearing, industrial oils, and coolants.

oPublic Infrastructure: Low Smoke Zero Halogen (LSZH) compounding. Prevents toxic, corrosive gas release during fire to protect personnel and electronics.

♦ Testing & Compliance: All shipments include datasheets, dielectric strength, and insulation resistance test reports. Supports third-party witness testing (TÜV, CE, KEMA).

Technical Specifications

♦ Voltage: 300/500V, 450/750V, 0.6/1kV.

♦ Cores: 2 to 61 cores.

♦ Size Range: 0.75 mm² to 10 mm² (AWG sizes available).

♦ Materials:

o Conductors: High-purity plain annealed copper (Class 2 rigid or Class 5 flexible).

o Insulation: Industrial PVC, XLPE, or LSZH.

o Shielding: Copper wire braid (BCWB/TCWB), double copper tape, or aluminum foil with drain wire.

oJacket: Flame-retardant PVC, heavy-duty PUR, or halogen-free LSZH.

♦ Standards: IEC 60227-7, VDE 0250, DIN EN 50525.
